EPYCD8-2T / EPYCD8 / EPYCD8-2T/R32 / EPYCD8/R32
18 19
English
Please make sure that the carrier
frame with CPU is closely attached to
the rail frame while inserting it.
5
6
Install the carrier frame with CPU. Don’t separate them.
Carrier Frame with CPU
Rail Frame
Please make sure that the carrier
frame with CPU is closely attached to
the rail frame while inserting it.
5
6
Install the carrier frame with CPU. Don’t separate them.
Carrier Frame with CPU
Rail Frame
