ASROCK 775XFIRE-RAID - IDE Configuration

4040
4040
40
BIOS SETUP UTILITY
IDE Configuration
Set [Compatible]
when Legacy OS
(MS-DOS, WinNT)
is used.
Set [Enhanced]
when Native OS
(Win2000 / XP)
is used.
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
ATA/IDE Configuration
IDE1 Master
IDE1 Slave
SATA_0
SATA_1
SATA_2
SATA_3
[Enhanced]
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
[ATAPI CDROM]
[Not Detected]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Configure SATA as
[AHCI]
3.3.43.3.4
3.3.43.3.4
3.3.4
IDE ConfigurationIDE Configuration
IDE ConfigurationIDE Configuration
IDE Configuration
ATA/IDE Configuration
Please select [Compatible] when you install legacy OS (Windows NT). If
native OS (Windows 2000 / XP) is installed, please select [Enhanced].
Then in the option “Configure SATA as”, you are allowed to set the selection
from [AHCI] to [RAID] if you plan to enable RAID function. Configuration
options: [AHCI], [IDE], and [RAID]. The default value is [AHCI].
When [Compatible] is selected
Combined Option
It allows you to select between [SATA 0, SATA 1, SATA 2, SATA 3], [SATA
0, SATA 2, IDE 1], and [IDE 1, SATA 1, SATA 3]. If it is set to [SATA 0, SATA
2, IDE 1], then SATA1, SATA3 will not work. Likewise, if it is set to [IDE 1,
SATA 1, SATA 3], then SATA0, SATA2 will not work.
Because Intel
®
ICH6R south bridge only supports four IDE devices
under legacy OS (Windows NT), you have to choose [SATA 0, SATA 1,
SATA 2, SATA 3], [SATA 0, SATA 2, IDE 1], or [IDE 1, SATA 1, SATA 3]
when the installed device is used with legacy OS.
[SATA 0, SATA 1, [SATA 0, SATA 2, [IDE 1, SATA 1,
SATA 2, SATA 3] IDE 1] SATA 3]
Master SATA0, SATA1 SATA0 SATA1
Slave SATA2, SATA3 SATA2 SATA3
1. AHCI (Advanced Host Controller Interface) supports Hot
Plug, NCQ and other new features that will improve SATA
disk performance but IDE mode does not have these
advantages.
2. Only AHCI and RAID modes support Hot Plug function.
