4747
4747
47
3.3.
3.3.
3.
UEFI SETUP UTILITYUEFI SETUP UTILITY
UEFI SETUP UTILITYUEFI SETUP UTILITY
UEFI SETUP UTILITY
3.1 Introduction3.1 Introduction
3.1 Introduction3.1 Introduction
3.1 Introduction
This section explains how to use the UEFI SETUP UTILITY to configure your system.
The SPI Memory on the motherboard stores the UEFI SETUP UTILITY. You may run the
UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del>
during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY, otherwise,
POST will continue with its test routines.
If you wish to enter the UEFI SETUP UTILITY after POST, restart the system by
pressing <Ctl> + <Alt> + <Delete>, or by pressing the reset button on the system
chassis. You may also restart by turning the system off and then back on.
Because the UEFI software is constantly being updated, the following
UEFI setup screens and descriptions are for reference purpose only,
and they may not exactly match what you see on your screen.
3.1.13.1.1
3.1.13.1.1
3.1.1
UEFI Menu BarUEFI Menu Bar
UEFI Menu BarUEFI Menu Bar
UEFI Menu Bar
The top of the screen has a menu bar with the following selections:
Main To set up the system time/date information
OC Tweaker To set up overclocking features
Advanced To set up the advanced UEFI features
H/W Monitor To display current hardware status
Boot To set up the default system device to locate and load the
Operating System
Security To set up the security features
Exit To exit the current screen or the UEFI SETUP UTILITY
Use < > key or < > key to choose among the selections on the menu bar,
and then press <Enter> to get into the sub screen.
