Power Down Enable
Use this item to enable or disable DDR power down mode.
Bank Interleaving
Interleaving allows memory accesses to be spread out over banks on the
same node, or accross nodes, decreasing access contention.
Channel Interleaving
It allows you to enable Channel Memory Interleaving. Conguration op-
tions: [Disabled], [Auto]. The default value is [Auto].
CAS Latency (CL)
Use this item to change CAS Latency (CL) Auto/Manual setting. The
default is [Auto].
TRCD
Use this item to change TRCD Auto/Manual setting. The default is [Auto].
TRP
Use this item to change TRP Auto/Manual setting. The default is [Auto].
HT Bus Width
This feature allows you selecting Hyper-Transport bus width. The default
value is [Auto].
Memory Conguration
Memory Clock
This item can be set by the code using [Auto]. You can set one of the stan-
dard values as listed: [400MHz DDR3_800], [533MHz DDR3_1066],
[667MHz DDR3_1333] and [800MHz DDR3_1600].
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s)
inserted and assigns appropriate frequency automatically.
Memory Timing
BIOS SETUP UTILITY
Memory Timing
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 ( C) Copyright 1985-2003, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Bank Interleaving
Channel Interleaving
[Auto]
[Auto]
Power Down Enable
[Disabled]
CAS Latency (CL)
TRCD
TRP
TRAS
Command Rate
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
TRC
TWR
TRFC
TRRD
TWTR
TRTP
TFAW
TCWL
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
