ASROCK 980DE3/U3S3 User Manual

43
3.4.4 Storage Conguration
Onboard SATA Controller
This item is for SATA2 ports. Use this item to enable or disable the “Onboard
SATA Controller” feature.
SATA Operation Mode
This item is for SATA2 ports. Use this item to adjust Onboard SATA Opera-
tion Mode. The default value of this option is [AHCI]. Conguration options:
[AHCI], [IDE] and [RAID].
If you set this item to RAID mode, it is suggested to install SATA ODD
driver on SATAII_5 (PORT 4) and SATAII_6 (PORT 5) ports.
SATA IDE Combined Mode
This item is for SATAII_5 (PORT 4) and SATAII_6 (PORT 5) ports. Use this
item to enable or disable SATA IDE combined mode. The default value is
[Enabled].
If you want to build RAID on SATAII_5 (PORT 4) and SATAII_6 (PORT 5
ports, please disable this item.
Onboard SATA3 Operation Mode
This item is for SATA3 ports. Use this item to adjust Onboard SATA3 Op-
eration Mode. The default value of this option is [AHCI]. Conguration op-
tions: [IDE], [AHCI] and [Disabled].
BIOS SETUP UTILITY
Storage Configuration
v02.54 ( C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Onboard SATA Controller
SATA Operation Mode
SATA IDE Combined Mode
Onboard SATA3 Operation Mode
IDE1 Master
IDE1 Slave
SATAII_1
SATAII_2
SATAII_3
SATAII_4
SATAII_5
SATAII_6
[Enabled]
[AHCI]
[Enabled]
[AHCI]
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Configure onboard
serial ATA
contr oller.

ASROCK 980DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
Maximum number of SMP processors	1
Processor system buses supported	2600 MHz
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	IDE, SATA II, SATA III
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	16 Mbit

Weight and Dimensions

Width	- mm
