ASROCK athena A1 User Manual

2 3
English
1.2 Specications
athena A1
Processor System
CPU Intel® Atom Apollo Lake J3455 processor
Chipset SoC
BIOS AMI SPI 128 Mbit
Memory
Technolog y Onboard LPDDR4 2400 MHz
Capacity 4 GB, up to 8GB
Graphics
Controller SoC integrated graphics
HDMI micro-HDMI 1.4b
Max resolution up to 3840x2160@30Hz
Expansion Slot
M.2 1 x M.2 (Key E, 2230) with PCIe x1 and USB 2.0 for Wireless
SIM Socket 1 x micro SIM Socket connected to M.2 Key B 3042
Ethernet
Controller/
Speed
LAN: 1 x Realtek® RTL8111G with 10/100/1000 Mbps
(PoE (PD) with 25.5W)
Connector 1 x RJ-45
Rear I/O
HDMI 1 x micro-HDMI 1.4b
Ethernet 1 x 1 Gigabit LAN, PoE (PD) with 25.5W
USB 1 x USB 3.1 (Gen1)
others 1 x Micro SD connector
Internal Connector
USB
1 x USB 2.0 header
1 x USB 3.1 (Gen 1) Connector for Movidius module
TPM TPM 2.0 onboard IC
IPCAM interface
LAN signal 1x6 header
Power 1x2 header
Storage
M.2
1 x M.2 (Key B, 3042) with PCIe x1 and shared SATA3 for SSD,
USB 3.0, and USB 2.0
eMMC Onboard eMMC 32GB
Watchdog Timer
Output From Super I/O to drag RESETCON#
Interval 256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWR 12V DC-In (DC Jack)
PoE (PD) with 25.5W (LAN Port)
Power On AT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on aer power input ready

ASROCK athena A1 Specifications

General

Brand	ASROCK
Model	athena A1
Category	Motherboard
Language	English
