ASROCK B150M Pro4/Hyper User Manual

1
English
B150M Pro4/Hyper
Motherboard Layout
Intel
B150
Super
I/O
ATXPWR1
HDLED RESET
PLED PWRBTN
PANEL1
1
COM1
1
B150M Pro4/Hyper
RoHS
2
3
6
1
Audio
CODEC
PCIE1
PCI Express 3.0
TPMS1
1
1
USB1_2
USB 3.0
T: USB1
B: USB2
PS2
Keyb oar d
/Mou se
SPK_CI1
1
PCIE2
Front USB 3.0
16
171820212223
CMOS
Battery
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module) DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
5
4
ATX 12V1
12
9
SATA3 _2
SATA3 _3
USB 3_5_6
13
14
15
SATA3 _4
SATA3 _5
BIOS
ROM
CHA_FAN2
10
11
CLRMOS1
1
1
HD_AUDIO1
PCIE3
Top:
RJ-45
USB 3.0
T: USB3
B: USB4
HDMI1
Top:
SIDE SP K
Cente r:
REAR SP K
Botto m:
CTR BAS S
Top:
LINE IN
Cente r:
FRONT
Botto m:
MIC IN
CHA_FAN1
24
8
SATA3 _1
7
SATA3 _0
VGA1
DVI1
CT4
M2_1
CT2
CT3
CT1
PCI1
Ultra M.2
PCIe Gen3 x4
CPU_FAN2CPU_FAN1
USB3_4
19

ASROCK B150M Pro4/Hyper Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Slots	4 x DIMM
Max Memory	64GB
Memory Support	DDR4 2133 MHz
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA3
USB Ports	6 x USB 3.0 (2 Front, 4 Rear) 6 x USB 2.0 (4 Front, 2 Rear)
Audio	Realtek ALC892 Audio Codec
Video Outputs	1 x DVI-D, 1 x HDMI
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
LAN	Gigabit LAN 10/100/1000 Mb/s
