ASROCK B150M Pro4/Hyper User Manual

6
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports 6
th
Generation Intel® Core
TM
i7/i5/i3/Pentium®/
Celeron® Processors (Socket 1151)
•
Digi Power design
•
6 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports ASRock Hyper BCLK Engine
Chipset
•
Intel
®
B150
•
Supports Intel® Small Business Advantage 4.0
Memory
•
Dual Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
Supports DDR4 2133 non-ECC, un-buered memory
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Max. capacity of system memory: 64GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
2 x PCI Express 3.0 x16 Slots (PCIE1: x16 mode; PCIE3: x4
mode)*
* Supports NVMe SSD as boot disks
•
1 x PCI Express 3.0 x1 Slot (Flexible PCIe)
•
1 x PCI Slot
* If PCI or PCIE2 slot is occupied, M2_1 slot will support M.2
PCI Express module up to Gen3 x2 (16 Gb/s).
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.

ASROCK B150M Pro4/Hyper Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Slots	4 x DIMM
Max Memory	64GB
Memory Support	DDR4 2133 MHz
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA3
USB Ports	6 x USB 3.0 (2 Front, 4 Rear) 6 x USB 2.0 (4 Front, 2 Rear)
Audio	Realtek ALC892 Audio Codec
Video Outputs	1 x DVI-D, 1 x HDMI
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
LAN	Gigabit LAN 10/100/1000 Mb/s
