ASROCK B150M Pro4/Hyper User Manual

7
English
B150M Pro4/Hyper
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 510/530
•
Pixel Shader 5.0, DirectX 12
•
Max. shared memory 1024MB
* e size of maximum shared memory may vary from dierent
operating systems.
•
ree graphics output options: D-Sub, DVI-D and HDMI
•
Supports Triple Monitor
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
•
Supports Accelerated Media Codecs: HEVC, VP8, VP9
•
Supports HDCP with DVI-D and HDMI Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI Ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection (ASRock Full Spike Protection)
•
ELNA Audio Caps
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Giga PHY Intel® I219V
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE

ASROCK B150M Pro4/Hyper Specifications

General

Form Factor	Micro ATX
Chipset	Intel B150
Socket	LGA 1151
Memory Slots	4 x DIMM
Max Memory	64GB
Memory Support	DDR4 2133 MHz
RAID Support	RAID 0, 1, 5, 10
Storage Interface	6 x SATA3
USB Ports	6 x USB 3.0 (2 Front, 4 Rear) 6 x USB 2.0 (4 Front, 2 Rear)
Audio	Realtek ALC892 Audio Codec
Video Outputs	1 x DVI-D, 1 x HDMI
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
LAN	Gigabit LAN 10/100/1000 Mb/s
