ASROCK B560M-ITX/ac User Manual

154
Bahasa Indonesia
I/O Panel
Belakang
•
2 x Port Antena
•
1 x Port Mouse/Keyboard PS/2
•
1 x Port HDMI
•
1 x DisplayPort 1.4
•
2 x Port USB 3.2 Gen1 (Mendukung Perlindungan dari ESD)
•
2 x Port USB 2.0 (Mendukung Perlindungan dari ESD)
•
1 x Port LAN RJ-45 dengan LED (LED ACT/LINK dan LED
SPEED)
•
Soket Audio HD: Saluran Masuk/Speaker Depan/Mikrofon
Penyimpanan
•
4 x Konektor SATA3 6,0 Gb/s, mendukung Intel Rapid Storage
Technology 18, NCQ, AHCI, dan Hot Plug*
* Jika M2_1 digunakan perangkat SATA tipe M.2, maka SATA3_0
akan dinonaktian.
•
1 x Soket Hyper M.2 (M2_1), mendukung jenis modul 2280 M.2
SATA3 6,0 Gb/s dan modul M.2 PCI Express hingga Gen4 x4
(64 Gb/s) (dengan Prosesor Intel® Core
TM
Gen 11) atau Gen3
x4 (32 Gb/s) (dengan Prosesor Intel® Core
TM
Gen 10)**
** Mendukung SSD NVMe sebagai disk boot
** Mendukung Kit ASRock U.2
Konektor
•
1 x Header Chassis Intrusion
•
1 x Addressable LED Header
* Mendukung total Strip LED hingga 5V/3A, 15W
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis (4-pin)
* Konektor Kipas Sasis mendukung kipas sasis dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis/Pompa Air (4-pin) (Kontrol
Kecepatan Kipas Pintar)
* Chassis/Kipas Pompa Air mendukung kipas berpendingin air
dengan daya kipas maksimum 2A (24W).
* CHA_FAN1/WP dapat mendeteksi otomatis jika kipas 3-pin atau
4-pin sedang digunakan.
•
1 x Konektor Daya ATX 24 pin
•
1 x Konektor Daya 8 pin 12V
•
1 x Konektor Audio Panel Depan
•
1 x Header USB 2.0 (Mendukung 2 port USB 2.0) (Mendukung
Perlindungan dari ESD)

ASROCK B560M-ITX/ac Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	4400, 4600 MHz
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	-
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel B560
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
BIOS type	UEFI AMI
ACPI version	6.0
System Management BIOS (SMBIOS) version	2.7
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
