ASROCK B560M-ITX/ac User Manual

English
2
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 Chassis/Waterpump Fan Connector (CHA_FAN1/WP)
4 Addressable LED Header (ADDR_LED1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6 ATX Power Connector (ATXPWR1)
7 Front Panel Type C USB 3.2 Gen1 Header (USB31_TC_1)
8 USB 3.2 Gen1 Header (USB3_3_4)
9 SATA3 Connector (SATA3_1)
10 SATA3 Connector (SATA3_0)
11 SATA3 Connector (SATA3_3)
12 SATA3 Connector (SATA3_2)
13 System Panel Header (PANEL1)
14 USB 2.0 Header (USB_3_4)
15 Clear CMOS Jumper (CLRMOS1)
16 Chassis Speaker Header (SPEAKER1)
17 Chassis Fan Connector (CHA_FAN2)
18 Chassis Intrusion Header (CI1)
19 Front Panel Audio Header (HD_AUDIO1)

ASROCK B560M-ITX/ac Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	4400, 4600 MHz
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	-
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel B560
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
BIOS type	UEFI AMI
ACPI version	6.0
System Management BIOS (SMBIOS) version	2.7
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
