B650D4U
B650D4U-2L2T
B650D4U-2L2T/BCM
2 3
English
Ethernet
Additional
Ethernet
Controller
B650D4U-2L2T/BCM:
Broadcom BCM57416: 2 RJ45 (10GbE)
Intel® i210: 2 RJ45 (1GbE)
B650D4U-2L2T:
Intel® X710: 2 RJ45 (10GbE)
Intel® i210: 2 RJ45 (1GbE)
B650D4U:
Intel® i210: 2 RJ45 (1GbE)
USB
Controller/Hub AMD B650E, CPU
Connectors/
Headers
External:
4 Type-A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
1 header (9-pin, 2 USB2.0)"
Graphics
Controller ASPEED AST2600:
1 DB15 (VGA), 1 (15-pin) header
AMD Processors with Graphics:
1 HDMI, 1 DisplayPort
Security
TPM 1 (13-pin, SPI)
Rear I/O
UID Button/LED 1 UID button w/ LED
VGA Port 1 DB15 (VGA), 1 DisplayPort, 1 HDMI
Serial Port 1 DB9 (COM)
USB 4 Type-A (USB3.2 Gen1)
RJ45 B650D4U-2L2T/BCM / B650D4U-2L2T:
2 RJ45 (10GbE), 2 RJ45 (1GbE), 1 dedicated IPMI
B650D4U:
2 RJ45 (1GbE), 1 dedicated IPMI
Hardware Monitor
Temperature CPU, DDR, MB, Card Side, Chipset, 10G LAN, M.2 slot
Fan Fan Tachometer, Multi-Speed Control, CPU Quiet Fan (Allow
Chassis Fan Speed Auto-Adjust by CPU Temperature)
Volt age VOLT_3VSB, VOLT_5VSB, VOLT_P0_VCORE, VOLT_
P0_VSOC, VOLT _VMEM, VOLT _VMISC, VOLT_1.8V_
PT21, VOLT_VSUS10, VOLT_VDD10, VOLT_V10_PHY_
DIG, VOLT_VDD_1P8, VOLT_MD_VDDO, VOLT_BAT,
VOLT_3V, VOLT_5V, VOLT_12V
