1.5 Block Diagram
Channel B Channel A
DDR5 Slot x2 DDR5 Slot x2
AZ(HD Audio) SPI eSPI
SIO NCT6796D-S Flash ROM Audio Codec ALC897 3
PCIe x16 Gen4 Slot
x4 Gen5
M.2(PCIe x4)
PCIe x4 Gen4 BUS
1st AMD PROM21 Chipset
AMD AM5 Processor LGA1718
DP0
HDMI Port
Rear USB 2.0 4 port
x16 Gen4 x1 10Gb/s
Rear USB 3.2 Gen2 Type A
10Gb/s
Rear USB 3.2 Gen2 Type C
DP1
Displayport
ReDriver5Gb/s
Rear USB 3.2 Gen1 1 port
x4 Gen4
PCIe x4 Slot
x1
Realtek RTL8125B 2.5G LAN Key E WiFi
Front USB 2.0 4 port
480Mb/s
M.2(PCIe x4 Gen4)
x4 Gen4 x1 x1
PCIe x1 Slot PCIe x1 Slot
SATA 4 port
SATA 6Gb 5Gb/s
Rear USB 3.2 Gen1 1 port
480Mb/s
ReDriver
USB2.0 Hub GL852
5Gb/s
Front USB 3.2 Gen1 4 port
5Gb/s
Front USB 3.2 Gen1 Type C

ASROCK B650M PG Riptide WiFi Specifications

General

Processor socket	Socket AM5
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen
Maximum number of SMP processors	1
Audio chip	Realtek ALC897
Certification	- FCC, CE - ErP/EuP ready
Component for	PC
Motherboard chipset	AMD B650
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
LAN controller	Dragon RTL8125BG
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
PCI Express x1 (Gen 3.x) slots	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
RAID levels	0, 1, 10
Supported storage drive interfaces	M.2, SATA III
Cables included	SATA
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel processing technology support	-

Weight and Dimensions

Width	244 mm
