ASROCK B650M PG Riptide WiFi - Page 29

25
B650M PG Riptide WiFi
6
CPU_FAN1
RGB_LED1
CPU_FAN1
RGB_LED1
USB_1_2
Please note that only one cable should be used at a time in this step.
If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC".
If you select USB connector, please install AMD utility "SR3 Settings Soware".
*e illustrations shown here are for reference purposes only and may not exactly match
the model you purchase.
+12V
or
