D1540D4U Series
8
9
English
No. Description
34
COM Port Header (COM2)
35
BMC SMB Header (BMC_SMB1)
36
Intelligent Platform Management Bus Header (IPMB1)
37
PMBUS Mode Jumper (PMBUS_ALT_SEL)
38
PMBUS Mode Jumper (PMBUS_CLK_SEL)
39
PMBUS Mode Jumper (PMBUS_DATA_SEL)
