No. Description
34
ME Recovery Jumper (ME_RECOVERY1)
35
COM Port Header (COM2)
36
BMC SMB Header (BMC_SMB1)
37
Intelligent Platform Management Bus Header (IPMB1)
38
PMBUS Mode Jumper (PMBUS_ALT_SEL)
39
PMBUS Mode Jumper (PMBUS_CLK_SEL)
40
PMBUS Mode Jumper (PMBUS_DATA_SEL)
