Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.7, 10, 13 or 16)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.7, 10, 13 or 16)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.7, 10, 13 or 16)
Board Level SKU (Default) For 3U8G system, passive
GPGPU
Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.7, 10, 13 or 16)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.7, 10, 13 or 16)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.7, 10, 13 or 16)
For 3U8G system, active
GPGPU
Reserved for system level use
Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.7, 10, 13 or 16)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.7, 10, 13 or 16)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.7, 10, 13 or 16)
Reserved for system level use Reserved for system level use
