ASROCK Fatal1ty Z77 Professional Series User Manual

6
2.21.2 Installing Windows
®
7 / 7 64-bit / Vista
TM
/
Vista
TM
64-bit Without RAID Functions ............... 60
2.22 Teaming Function Operation Guide ............................ 61
3 UEFI SETUP UTILITY ................................................. 65
3.1 Introduction .................................................................... 65
3.1.1 UEFI Menu Bar .................................................... 65
3.1.2 Navigation Keys ................................................... 66
3.2 Main Screen ................................................................... 66
3.3 OC Tweaker Screen ...................................................... 67
3.4 Advanced Screen ........................................................... 72
3.4.1 CPU Confi guration ............................................... 72
3.4.2 North Bridge Confi guration................................... 73
3.4.3 South Bridge Confi guration .................................. 75
3.4.4 Intel(R) Rapid Start Technology ........................... 77
3.4.5 Intel(R) Smart Connect Technology ..................... 78
3.4.6 Storage Confi guration .......................................... 79
3.4.7 Super IO Confi guration ........................................ 80
3.4.8 ACPI Confi guration............................................... 81
3.4.9 USB Confi guration ............................................... 82
3.5 Hardware Health Event Monitoring Screen ................... 83
3.6 Boot Screen ................................................................... 84
3.7 Security Screen ............................................................. 85
3.8 Exit Screen .................................................................... 86
4 Software Support ................................................. 87
4.1 Install Operating System ................................................ 87
4.2 Support CD Information ................................................. 87
4.2.1 Running Support CD ............................................ 87
4.2.2 Drivers Menu ........................................................ 87
4.2.3 Utilities Menu........................................................ 87
4.2.4 Contact Information .............................................. 87

ASROCK Fatal1ty Z77 Professional Series Specifications

General

Chipset	Intel Z77
CPU Socket	LGA 1155
Max Memory	32 GB
PCIe 3.0 x16 Slots	3
PCIe 2.0 x1 Slots	2
PCI Slots	2
SATA 6Gb/s	4
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
Form Factor	ATX
Memory Slots	4 x DIMM
Memory Speed	DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
USB 3.0 Ports	4 (2 rear, 2 via header)
USB 2.0 Ports	8 (4 rear, 4 via headers)
Audio	Realtek ALC898
Video Outputs	HDMI
Multi-GPU Support	Supports NVIDIA Quad SLI and AMD Quad CrossFireX
