ASROCK Fatal1ty Z77 Professional Series User Manual

9
- Pixel Shader 5.0, DirectX 11 with Intel
®
Ivy Bridge CPU.
Pixel Shader 4.1, DirectX 10.1 with Intel
®
Sandy Bridge
CPU.
- Max. shared memory 1760MB (see CAUTION 5)
- Dual VGA Output: support HDMI and DisplayPort ports by
independent display controllers
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
- Supports DisplayPort with max. resolution up to 2560x1600
@ 60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required) (see CAUTION 6)
- Supports HDCP function with HDMI and DisplayPort ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with HDMI and DisplayPort ports
Audio - 7.1 CH HD Audio with Content Protection
(Realtek ALC898 Audio Codec)
- Premium Blu-ray audio support
- Supports THX TruStudio
TM
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Broadcom BCM57781
- Supports Wake-On-LAN
- Supports Energy Effi cient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
Rear Panel I/O I/O Panel
- 1 x PS/2 Keyboard/Mouse Port
- 1 x HDMI Port
- 1 x DisplayPort
- 1 x Optical SPDIF Out Port
- 5 x Ready-to-Use USB 2.0 Ports
- 1 x Fatal1ty Mouse Port (USB 2.0)
- 1 x eSATA3 Connector
- 6 x Ready-to-Use USB 3.0 Ports
- 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
- 1 x IEEE 1394 Port
- 1 x Clear CMOS Switch with LED
- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front
Speaker/Microphone (see CAUTION 7)

ASROCK Fatal1ty Z77 Professional Series Specifications

General

Chipset	Intel Z77
CPU Socket	LGA 1155
Max Memory	32 GB
PCIe 3.0 x16 Slots	3
PCIe 2.0 x1 Slots	2
PCI Slots	2
SATA 6Gb/s	4
SATA 3Gb/s	4
RAID Support	RAID 0, 1, 5, 10
Form Factor	ATX
Memory Slots	4 x DIMM
Memory Speed	DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
USB 3.0 Ports	4 (2 rear, 2 via header)
USB 2.0 Ports	8 (4 rear, 4 via headers)
Audio	Realtek ALC898
Video Outputs	HDMI
Multi-GPU Support	Supports NVIDIA Quad SLI and AMD Quad CrossFireX
