ASROCK Fatal1ty Z97M Killer Series User Manual

2
English
1.2 Specications
Platform
•Micro ATX Form Factor
•High Density Glass Fabric PCB
CPU
•Supports 4
th
Gen & 5
th
Generation Intel® Core
TM
Processors
(Socket 1150)
•Digi Power design
•8 Power Phase design
•Supports Intel® Turbo Boost 2.0 Technology
•Supports Intel® K-Series unlocked CPUs
•Supports ASRock BCLK Full-range Overclocking
Chipset
•Intel® Z97
Memory
•Dual Channel DDR3 Memory Technology
•4 x DDR3 DIMM Slots
•Supports DDR3 3000+(OC)/2933(OC)/2800(OC)/2400(OC)/
2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buered
memory
•Max. capacity of system memory: 32GB
•Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2
Expansion
Slot
•2 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3: single at x16
(PCIE1); dual at x8 (PCIE1) / x8 (PCIE3))
•1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)
•1 x PCI Express 2.0 x1 Slot
•Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
•Supports NVIDIA® Quad SLI
TM
and SLI
TM

ASROCK Fatal1ty Z97M Killer Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel Z97
CPU Socket	LGA 1150
Max Memory	32GB
Audio Codec	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
PCIe Slots	2 x PCIe 3.0 x16
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.0
Audio	7.1 CH HD Audio with Content Protection
LAN	Killer E2200 Series
Memory Speed	DDR3 3200+(OC)/2933(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory
M.2 Specification	M.2 (PCIe 2.0 x2 & SATA)
