ASROCK Fatal1ty Z97M Killer Series User Manual

83
English
Fatal1ty Z97M Killer Series
installed. Select enable to keep the integrated graphics enabled at all times.
Render Standby
Power down the render unit when the GPU is idle for lower power consumption.
Onboard HD Audio
Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and
automatically disable it when a sound card is installed.
Front Panel
Enable/disable front panel HD audio.
Onboard HDMI HD Audio
Enable audio for the onboard digital outputs.
Onboard LAN
Enable or disable the onboard network interface controller.
Deep Sleep
Congure deep sleep mode for power saving when the computer is shut down.
Restore on AC/Power Loss
Select the power state aer a power failure. If [Power O] is selected, the power will
remain o when the power recovers. If [Power On] is selected, the system will start
to boot up when the power recovers.
Good Night LED
By enabling Good Night LED, the Power/HDD LEDs will be switched o when the
system is on. It will also automatically switch o the Power and Keyboard LEDs
when the system enters into Standby/Hibernation mode.
DMI Gen 2
Congure the speed of the bus between the CPU and PCH.
DMI De-emphasis Control
Reduce the level of all bits except the rst one aer a transition for the bus between
the CPU and PCH. Users may select -6dB for better overclocking results.
PCIE1 De-emphasis Control
Reduce the level of all bits except the rst one aer a transition for the rst PCIEx16
slot. Users may select -6dB for better overclocking results.

ASROCK Fatal1ty Z97M Killer Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel Z97
CPU Socket	LGA 1150
Max Memory	32GB
Audio Codec	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
PCIe Slots	2 x PCIe 3.0 x16
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.0
Audio	7.1 CH HD Audio with Content Protection
LAN	Killer E2200 Series
Memory Speed	DDR3 3200+(OC)/2933(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory
M.2 Specification	M.2 (PCIe 2.0 x2 & SATA)
