2.3 Installing Memory Modules (DIMM)
is motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM slots,
and supports Dual Channel Memory Technology.
Dual Channel Memory Conguration
e DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
Priority DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2
1 Populated Populated
2 Populated Populated
3 Populated Populated Populated Populated
1. For dual channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR3 DIMM pairs.
2. It is unable to activate Dual Channel Memory Technology with only one or three memory
module installed.
3. It is not allowed to install a DDR or DDR2 memory module into a DDR3 slot; otherwise,
this motherboard and DIMM may be damaged.

ASROCK Fatal1ty Z97M Killer Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel Z97
CPU Socket	LGA 1150
Max Memory	32GB
Audio Codec	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
PCIe Slots	2 x PCIe 3.0 x16
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.0
Audio	7.1 CH HD Audio with Content Protection
LAN	Killer E2200 Series
Memory Speed	DDR3 3200+(OC)/2933(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory
M.2 Specification	M.2 (PCIe 2.0 x2 & SATA)
