ASROCK Fatal1ty Z97M Killer Series User Manual

4
English
LAN
•PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•Qualcomm® Atheros® Killer
TM
E2200 Series
• Supports Qualcomm® Atheros® Security Wake On Internet
Technology
•Supports Wake-On-LAN
•Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
•Supports Energy Ecient Ethernet 802.3az
•Supports PXE
Rear Panel
I/O
•1 x PS/2 Mouse/Keyboard Port
•1 x D-Sub Port
•1 x DVI-D Port
•1 x HDMI Port
•1 x Optical SPDIF Out Port
•1 x eSATA Connector
•3 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•1 x Fatal1ty Mouse Port (USB 2.0) (Supports ESD Protection
(ASRock Full Spike Protection))
•4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Storage
•6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
13 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug (SATA3_1 connector is shared with the eSATA port)
•1 x SATA Express Connector (shared with SATA3_4,
SATA3_5 and M.2 Socket)
*Support to be announced
•1 x eSATA Connector, supports RAID (RAID 0, RAID 1,
RAID 5, RAID 10, Intel Rapid Storage Technology 13 and
Intel Smart Response Technology), NCQ, AHCI and Hot Plug
•1 x M.2_SSD (NGFF) Socket 3, supports M.2 SATA3 6.0 Gb/s
module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s)

ASROCK Fatal1ty Z97M Killer Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel Z97
CPU Socket	LGA 1150
Max Memory	32GB
Audio Codec	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
PCIe Slots	2 x PCIe 3.0 x16
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.0
Audio	7.1 CH HD Audio with Content Protection
LAN	Killer E2200 Series
Memory Speed	DDR3 3200+(OC)/2933(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory
M.2 Specification	M.2 (PCIe 2.0 x2 & SATA)
