Ratio Status
This is a read-only item, which displays whether the ratio status of this
motherboard is “Locked” or “Unlocked”. If it shows “Unlocked”, you will find
an item Ratio CMOS Setting appears to allow you changing the ratio
value of this motherboard.
Ratio CMOS Setting
If the ratio status is unlocked, you will find this item appear to allow you
changing the ratio value of this motherboard. If the CPU you adopt supports
EIST (Intel (R) SpeedStep(tm) tech.), and you plan to adjust the ratio value,
please disable the option “ Intel (R) SpeedStep(tm) tech.” in advance.
Intel (R) SpeedStep(tm) tech.
Intel (R) SpeedStep(tm) tech. is Intel’s new power saving technology.
Processor can switch between multiple frequency and voltage points to
enable power savings. The default value is [Auto]. Configuration options:
[Auto], [Enabled] and [Disabled]. If you install Windows
®
XP and select
[Auto], you need to set the “Power Schemes” as “Portable/Laptop” to en-
able this function. If you install Windows
®
Vista
TM
and want to enable this
function, please set this item to [Enabled]. This item will be hidden if the
current CPU does not support Intel (R) SpeedStep(tm) tech..
Please note that enabling this function may reduce CPU voltage and lead to system
stability or compatibility issue with some power supplies. Please set this item to
[Disable] if above issue occurs.
Overclock Mode
Use this to select Overclock Mode. The default value is [Auto]. Configura-
tion options: [Auto], [Manual] and [Optimized].
CPU Frequency (MHz)
Use this option to adjust CPU frequency.
PCIE Frequency (MHz)
Use this option to adjust PCIE frequency.
DRAM Voltage
Use this to select DRAM Voltage. Configuration options for DDR3: [Auto],
[1.48V] to [2.40V]. Configuration options for DDR2: [Auto], [1.80V] to
[2.73V]. The default value of this feature is [Auto].
NB Voltage
Use this to select NB Voltage. Configuration options: [Auto], [1.05V] to
[1.30V]. The default value of this feature is [Auto].
VTT Voltage
Use this to select VTT Voltage. Configuration options: [Auto], [1.10V] and
[1.20V]. The default value of this feature is [Auto].

ASROCK G41C-VS Specifications

General

Non-ECC	Yes
Number of memory slots	4
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Number of SATA connectors	2
ATX Power connector (24-pin)	No
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Certification	FCC, CE, EuP Ready
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Networking features	10/100 Mbps
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198 mm
Width	224 mm
