BIOS SETUP UTILITY
Storage Configuration
Set [Compatible]
when Legacy OS
(MS-DOS, Win NT)
device is used.
Set [Enhanced]
when Native OS
(Win2000 / XP)
is used.
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
ATA/IDE Configuration
[Enhanced]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
IDE1 Master
IDE1 Slave
SATAII_1
SATAII_2
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
3.4.43.4.4
3.4.43.4.4
3.4.4
Storage ConfigurationStorage Configuration
Storage ConfigurationStorage Configuration
Storage Configuration
ATA/IDE Configuration
Please select [Compatible] when you install legacy OS (Windows
®
NT). If
native OS (Windows
®
7 / Vista
TM
/ XP) is installed, please select
[Enhanced].
When [Compatible] is selected
Combined Option
It allows you to select between [SATA 1, SATA 2], [SATA 1, IDE 1], and
[PATA Only]. If it is set to [SATA 1, IDE 1], then SATAII_2 will not work.
Likewise, if it is set to [PATA Only], then SATAII_1 and SATAII_2 will not
work.
Because Intel
®
ICH7 south bridge only supports two IDE devices
under legacy OS (Windows NT), you have to choose [SATA 1, SATA2],
[SATA 1, IDE 1], or [PATA Only] when the installed device is used with
legacy OS.
[SATA 1, SATA 2] [SATA 1, IDE 1] [PATA Only]
Master SATAII 1, SATAII 2 SATAII 1 IDE1
IDE Device Configuration
You may set the IDE configuration for the device that you specify. We will
use the “Primary IDE Master” as the example in the following instruction.
ACPI HPET Table
Use this item to enable or disable ACPI HPET Table. The default value is
[Disabled]. Please set this option to [Enabled] if you plan to use this
motherboard to submit Windows
®
Vista
TM
certification.

ASROCK G41C-VS Specifications

General

Non-ECC	Yes
Number of memory slots	4
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Number of SATA connectors	2
ATX Power connector (24-pin)	No
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Certification	FCC, CE, EuP Ready
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Networking features	10/100 Mbps
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198 mm
Width	224 mm
