ASROCK H110M-DVS R3.0 User Manual

12
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports 7
th
and 6
th
Generation Intel® Core
TM
i7/i5/i3/
Pentium®/Celeron® Processors (Socket 1151)
•
4 Power Phase design
•
Supports CPU up to 95W
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H110
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 2133 non-ECC, un-buered memory
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
* Supports NVMe SSD as boot disks
•
1 x PCI Express 2.0 x1 Slot
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 510/530
•
Pixel Shader 5.0, DirectX 12
•
Max. shared memory 1024MB
* e size of maximum shared memory may vary from dierent
operating systems.

ASROCK H110M-DVS R3.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-6xxx, i5-6xxx, i7-6xxx
USB 2.0 connectors	1
Number of SATA II connectors	-
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Realtek RTL8111C
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887
Certification	FCC, CE, WHQL
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H110
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Home x64, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64
Cables included	SATA
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	64 Mbit
Graphics card	HD Graphics
DirectX version	12.0
Maximum resolution	1920 x 1200 pixels
Maximum graphics card memory	1024 MB

Weight and Dimensions

Depth	188 mm
Width	191 mm
