ASROCK H110M-HDS R3.0 User Manual

Name: ASROCK H110M-HDS R3.0
Brand: ASROCK
Rating: 4 (1 reviews)

79 pages

To Next Page

To Previous Page

English

H110M-HDV R3.0 / H110M-HDS R3.0 / H110M-DVS R3.0 / H110M-DGS R3.0

No. Description

1 ATX 12V Power Connector (ATX12V1)

2 CPU Fan Connector (CPU_FAN1)

3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)

4 Chassis Fan Connector (CHA_FAN1)

5 ATX Power Connector (ATXPWR1)

6 SATA3 Connectors (SATA3_2_3)

7 SATA3 Connectors (SATA3_0_1)

8 USB 3.0 Header (USB3_3_4)

9 USB 2.0 Header (USB_4_5)

10 System Panel Header (PANEL1)

11 Chassis Intrusion and Speaker Header (SPK_CI1)

12 TPM Header (TPMS1)

13 Front Panel Audio Header (HD_AUDIO1)
