ASROCK H110M-ITX/ac User Manual

7
English
H110M-ITX/ac
H110M-ITX
1.2 Specications
Platform
•
Mini-ITX Form Factor
•
Solid Capacitor design
CPU
•
Supports 6
th
Generation Intel® Core
TM
i7/i5/i3/Pentium®/
Celeron® Processors (Socket 1151)
•
Supports CPU up to 95W
•
Digi Power design
•
5 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H110
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 2133 non-ECC, un-buered memory
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
* Supports NVMe SSD as boot disks
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 510/530
•
Pixel Shader 5.0, DirectX 12
•
Max. shared memory 1792MB
•
Dual graphics output: Support DVI-D and HDMI ports by
independent display controllers
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz

ASROCK H110M-ITX/ac Specifications

General

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Processor thermal power (max)	95 W
Intel® Core i3/i5/i7/i9 series	i3-6xxx, i5-6xxx, i7-6xxx
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133 MHz
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	Mini PC
Power source type	ATX
Motherboard chipset	Intel® H110
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Cables included	SATA
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet interface type	Gigabit Ethernet
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	Not supported
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	64 Mbit
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	- mm
