ASRock XFast LAN UI Overview
The default status window
Right click for more options
Show/hide slot
activation area
Variance of
ping time
TX shaping
indicator
Open slot
conguration
dialog
Open Current
Connections window
Ping time in ms
Download CPS rate
Upload CPS rateGraphs Transfer rate
in % for slots 1-10
Upload activity display
Download activity display
Number of TCP/
UDP/TCP+UDP
connections
Low Latency Mode switch
arrow down = currently
on (if needed)
arrow up = always on
no arrow = off
