ASROCK H61MV-ITX User Manual

43
Close Windows
Hides the status window. Can also be done by double clicking on the status
window. Reopen by right clicking on the XFast LAN icon on the
bottom right and selecting Open windows.
Window settings
Users may congure the skin and effects of the user interface. Make the
keyboard LEDs display Trafc Shaping information. Or display the XFast
LAN status window on a Logitech gamer keyboard instead of Windows
desktop.
Trafc Shaping
Trafc Shaping is used to optimize or guarantee performance, improve
latency, and/or increase usable bandwidth for some kinds of packets by
delaying other kinds of packets that meet certain criteria. In other words, it
increases the speed while keeping the overall ping time low.
cFos Speed Test
Quickly test the upload and download speed of your Internet connection.
Speed Guide
This guide can either help you get the maximum out of your connection or
solve problems with speed, ping time or connections.
Current Connection
Shows the details of current internet connections.
Usage Graph
Displays the Usage Graph.
Options
Congure settings such as program prioritization, language and update the
program.
Documentation
Opens detailed help for XFast LAN in a browser.

ASROCK H61MV-ITX Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	8GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Number of SATA connectors	-
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	3.0
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit

Weight and Dimensions

Width	- mm
