45
Four Activate Window (tFAW)
Use this item to change Four Activate Window (tFAW) Auto/Manual set-
ting. The default is [Auto].
Memory Power Down Mode
Use this item to adjust DDR power down mode. Configuration options:
[Auto], [Slow] and [Fast]. The default value is [Auto].
Voltage Control
Power Saving Mode
Use this to enable or disable Power Saving Mode. The default value is
[Disabled].
DRAM Voltage
Use this to select DRAM Voltage. Confi guration options: [Auto], [1.250V]
to [1.800V]. The default value is [Auto].
PCH Voltage
Use this to select PCH Voltage. Confi guration options: [Auto], [1.05V] to
[1.15V]. The default value is [Auto].
VTT Voltage
Use this to select VTT Voltage. Confi guration options: [Auto], [1.05V] to
[1.15V]. The default value is [Auto].
VCCSA Voltage
Use this to select VCCSA Voltage. Confi guration options: [Auto], [0.925V]
to [1.107V]. The default value is [Auto].
VDroop
Use this to enable or disable VDroop. The default value is [Auto].
User Default
In this option, you are allowed to load and save three user defaults
according to your own requirements.
