BIOS SETUP UTILITY
Storage Configuration
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Advanced
Onboard IDE Controller
Onboard SATA Controller
[Enabled]
[Enabled]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
IDE1 Master
IDE1 Slave
SATAII_1
SATAII_2
SATAII_3
SATAII_4
eSATA5
eSATA6
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
SATA Operation Mode
[AHCI]
IDE
RAID
AHCI
Options
3.4.43.4.4
3.4.43.4.4
3.4.4
Storage ConfigurationStorage Configuration
Storage ConfigurationStorage Configuration
Storage Configuration
Onboard IDE Controller
Use this item to enable or disable the “Onboard IDE Controller” feature.
Onboard SATA Controller
Use this item to enable or disable the “Onboard SATA Controller” feature.
SATA Operation Mode
Use this item to adjust SATA Operation Mode. The default value of this
option is [AHCI]. If you want to operate RAID function on SATA / SATAII
HDDs, please select [RAID]. Configuration options: [IDE], [RAID] and [AHCI].
* If you select [RAID] mode, SATA / SATAII HDDs can not be accessed until you finish
configuring RAID functions in NVIDIA BIOS / Windows RAID Utility.
* If you install OS on SATA / SATAII HDDs, please do not change the setting of this
item after OS installation.
IDE Device Configuration
You may set the IDE configuration for the device that you specify. We will
use the “IDE1 Master” as the example in the following instruction, which can
be applied to the configurations of “IDE1 Slave” as well.
ACPI HPET Table
Use this item to enable or disable ACPI HPET Table. The default value is
[Disabled]. Please set this option to [Enabled] if you plan to use this
motherboard to submit Windows
®
Vista
TM
certification.
