ASROCK N68-GS4 FX R2.0 User Manual

66
66
6
1.2 Specifications1.2 Specifications
1.2 Specifications1.2 Specifications
1.2 Specifications
Platform - Micro ATX Form Factor
- Solid Capacitor design
CPU - Support for Socket AM3+ processors
- Support for AM3 processors: AMD Phenom
TM
II X6 / X4 / X3 /
X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron
processors (see CAUTION 1)
- Supports 8-Core CPU
- 4 + 1 Power Phase design
- Supports UCC feature (Unlock CPU Core) (see CAUTION 2)
- Supports AMD’s Cool ‘n’ Quiet
TM
Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset - NVIDIA
®
GeForce 7025 / nForce 630a
Memory - Dual Channel DDR3 Memory Technology
- 2 x DDR3 DIMM Slots
- Support DDR3 1866/1600/1333/1066 non-ECC, un-buffered
memory (see CAUTION 3)
- Max. capacity of system memory: 16GB (see CAUTION 4)
Expansion Slot - 1 x PCI Express x16 Slot
- 1 x PCI Express x1 Slot
- 1 x PCI Slot
Graphics - Integrated NVIDIA
®
GeForce 7025 graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Supports D-Sub with max. resolution up to 1920x1440
@ 60Hz
Audio - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)
* To configure 7.1 CH HD Audio, it is required to use an HD front
panel audio module and enable the multi-channel audio feature
through the audio driver.
- Supports Surge Protection (ASRock Full Spike Protection)
- ELNA Audio Caps
LAN - Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Realtek RTL8211E
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
- Supports Energy Efficient Ethernet 802.3az

ASROCK N68-GS4 FX R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
System bus rate	2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor system buses supported	1000 MHz
USB 2.0 connectors	2
Number of SATA connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
RAID levels	0, 0+1, 1, 5, JBOD
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
LAN controller	Realtek RTL8211E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Certification	FCC, CE, WHQL, ErP/EuP, ErP/EuP
Component for	PC
Motherboard chipset	NVIDIA nForce 630a
PC health monitoring	CPU
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	NVIDIA
USB version	2.0
Trial software	Google Chrome Browser and Toolbar
Cables included	SATA
Graphics card	GeForce 7025
DirectX version	9.0
Maximum resolution	1920 x 1440 pixels
Maximum graphics card memory	256 MB

Weight and Dimensions

Depth	183 mm
Width	221 mm
