Thank you for purchasing ASRock N68-VGS3 FX / N68-VS3 FX motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock’s commitment to qual-
ity and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-step
guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to
BIOS setup and information of the Support CD.
Because the motherboard specifications and the BIOS software might be
updated, the content of this manual will be subject to change without
notice. In case any modifications of this manual occur, the updated
version will be available on ASRock website without further notice. You
may find the latest VGA cards and CPU support lists on ASRock website
as well. ASRock website
http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specific information about the model you are using.
www.asrock.com/support/index.asp
1.11.1
1.11.1
1.1
PP
PP
P
ackack
ackack
ack
age Contentsage Contents
age Contentsage Contents
age Contents
One ASRock N68-VGS3 FX / N68-VS3 FX Motherboard
(Micro ATX Form Factor: 8.5-in x 7.0-in, 21.6 cm x 17.8 cm)
One ASRock N68-VGS3 FX / N68-VS3 FX Quick Installation Guide
One ASRock N68-VGS3 FX / N68-VS3 FX Support CD
Two Serial ATA (SATA) Data Cables (Optional)
One I/O Panel Shield

ASROCK N68-VS3 FX Specifications

General

CPU Socket	AM3+
Chipset	NVIDIA GeForce 7025 / nForce 630a
Memory Slots	2 x DDR3 DIMM
Maximum Memory	16GB
Expansion Slots	1 x PCI Express x16, 1 x PCI Express x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Form Factor	Micro ATX
Audio Chipset	VIA VT1705
LAN Chipset	Realtek RTL8201EL
Max. LAN Speed	10/100 Mbps
PS/2 Ports	1 x PS/2 keyboard, 1 x PS/2 mouse
Video Outputs	1 x VGA
