Page #12 background imageLoading...
Page #12 background image
1212
1212
12
1.3 Motherboard L1.3 Motherboard L
1.3 Motherboard L1.3 Motherboard L
1.3 Motherboard L
ayout (N68Cayout (N68C
ayout (N68Cayout (N68C
ayout (N68C
--
--
-
GS FX / N68CGS FX / N68C
GS FX / N68CGS FX / N68C
GS FX / N68C
-S FX)-S FX)
-S FX)-S FX)
-S FX)
1 PS2_USB_PWR1 Jumper 16 USB 2.0 Header (USB8_9, Blue)
2 CPU Fan Connector (CPU_FAN1) 17 USB 2.0 Header (USB6_7, Blue)
3 ATX 12V Power Connector (ATX12V1) 18 USB 2.0 Header (USB4_5, Blue)
4 CPU Heatsink Retention Module 19 Chassis Speaker Header
5 AMD CPU Socket (SPEAKER 1, White)
6 2 x 240-pin DDR2 DIMM Slots 20 System Panel Header (PANEL1, White)
(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Chassis Fan Connector (CHA_FAN1)
7 2 x 240-pin DDR3 DIMM Slots 22 Clear CMOS Jumper (CLRCMOS1)
(Dual Channel: DDR3_A1, DDR3_B1; Blue) 23 Print Port Header (LPT1, Purple)
8 ATX Power Connector (ATXPWR1) 24 Floppy Connector (FLOPPY1)
9 Primary IDE Connector (IDE1, Blue) 25 Power Fan Connector (PWR_FAN1)
10 Primary SATAII Connector (SATAII_1 (PORT 0.0)) 26 Internal Audio Connector: CD1 (White)
11 Third SATAII Connector (SATAII_3 (PORT 1.0)) 27 Front Panel Audio Header
12 Fourth SATAII Connector (SATAII_4 (PORT 1.1)) (HD_AUDIO1, White)
13 Secondary SATAII Connector 28 PCI Slots (PCI1- 2)
(SATAII_2 (PORT 0.1)) 29 PCI Express x16 Slot (PCIE2)
14 SPI Flash Memory (8Mb) 30 PCI Express x1 Slot (PCIE1)
15 USB_PWR2 Jumper 31 NVIDIA GeForce 7025 / nForce 630a
NVIDIA
GeForce
7025 /
nForce
630a
FSB800
DDRII_1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
IDE1
SATAII_1
SATAII_2 SATAII_4
(PORT 0.0)
(PORT 0.1) (PORT 1.1)
SATAII_3
(PORT 1.0)
CHA_FAN1
SPEAKER1
1
HDLED RESET
PLED PWRBTN
1
PANEL1
11
ATXPWR1
8Mb
BIOS
CMOS
BATTERY
1
CLRCMOS1
CPU_FAN1
ATX12V1
PS2_USB_PWR1
1
20.8cm (8.2-in)
24.4cm (9.6-in)
1
USB4_5
SOCKET AM2/AM3/AM3+
FSB800
DDRII_2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
1
USB6_7
1
USB8_9
HD_AUDIO1
1
FLOPPY1
CD1
LAN
PHY
AUDIO
CODEC
Super
I/O
PCIE1
PCIE2
PCI1
PCI2
PWR_FAN1
Phenom II
AM2+/AM3
DDR2 1066
Dual Channel
RoHS
1
24
3
6
7
5
8
9
10
11
12
13
14
15
16
17
1819
20
21
22
23
24
25
26
27
28
29
30
USB 2.0
T: U SB 0
B: USB1
Top:
RJ-45
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Mouse
PS2
Keyboard
VGA1
USB 2.0
T: USB2
B: USB3
COM1
1
LPT1
DDR3 1600
Designed in Taipei
Support 8-Core CPU
USB_PWR2
1
31

Table of Contents

Other manuals for ASROCK N68C-GS FX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK N68C-GS FX and is the answer not in the manual?

ASROCK N68C-GS FX Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR2-SDRAM, DDR3-SDRAM
Maximum internal memory8 GB
Supported memory clock speeds533, 667, 800, 1066, 1333, 1600 MHz
System bus rate2 GT/s
Processor socketSocket AM3+
Processor manufacturerAMD
Compatible processor seriesAMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Maximum number of SMP processors1
Processor system buses supported1000 MHz
USB 2.0 connectors3
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
PS/2 ports quantity2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CertificationFCC, CE, WHQL
Component forPC
Power source typeATX
Motherboard chipsetNVIDIA nForce 630a
Audio output channels5.1 channels
Motherboard form factormicro ATX
Motherboard chipset familyNVIDIA
RAID levels0, 1, 0+1, 5, JBOD
Supported storage drive interfacesSATA II
Graphics cardGeForce 7025
Maximum graphics card memory256 MB
Parallel processing technology support-
Cables includedSATA
LAN controllerRealtek RTL8211CL
Ethernet interface typeGigabit Ethernet
BIOS typeAMI
ACPI version1.1
BIOS memory size8 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth208 mm
Width244 mm
