ASROCK P67 PRO3 User Manual

4
2.18 Installing Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit
/ XP / XP 64-bit Without RAID Functions ................... 42
2.18.1 Installing Windows
®
XP / XP 64-bit Without RAID
Functions............................................................ 42
2.18.2 Installing Windows
®
7 / 7 64-bit / Vista
TM
/
Vista
TM
64-bit Without RAID Functions ............... 43
3 UEFI SETUP UTILITY ................................................. 44
3.1 Introduction .................................................................... 44
3.1.1 UEFI Menu Bar .................................................... 44
3.1.2 Navigation Keys ................................................... 45
3.2 Main Screen ................................................................... 45
3.3 Advanced Screen ........................................................... 46
3.3.1 CPU Confi guration ............................................... 47
3.3.2 Integrated Clock Chip Confi guration .................... 49
3.3.3 DRAM Confi guration ............................................ 50
3.3.4 North Bridge Confi guration................................... 52
3.3.5 South Bridge Confi guration .................................. 53
3.3.6 Storage Confi guration .......................................... 54
3.3.7 Super IO Confi guration ........................................ 55
3.3.8 Voltage Confi guration ........................................... 56
3.3.9 ACPI Confi guration............................................... 57
3.3.10 USB Confi guration .............................................. 58
3.4 Hardware Health Event Monitoring Screen ................... 59
3.5 Boot Screen ................................................................... 60
3.6 Security Screen ............................................................. 61
3.7 Exit Screen .................................................................... 62
4 Software Support ................................................. 63
4.1 Install Operating System ................................................ 63
4.2 Support CD Information ................................................. 63
4.2.1 Running Support CD ............................................ 63
4.2.2 Drivers Menu ........................................................ 63
4.2.3 Utilities Menu........................................................ 63
4.2.4 Contact Information .............................................. 63

ASROCK P67 PRO3 Specifications

General

Form Factor	ATX
Chipset	Intel P67
Socket	LGA 1155
Memory Slots	4 x DIMM
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16	2
PCI Express x1	2
PCI Slots	2
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 2.0 Ports	8
USB 3.0 Ports	2
LAN	Gigabit Ethernet
Audio	7.1 Channel HD Audio
