ASROCK PG34WQ15R3A User Manual

4
1.2 Installation Instructions
Leave the monitor in its protective foam packaging. Align the latches of the stand to the
monitor. Tighten the stand with screws.
Connect the stand base to the stand and tighten the screw to secure the stand base.
Align the latches to place the stand cover.
Adjust the angle of the stand, make sure the stand assembly is properly installed before
setting the monitor upright.
⚠
Important
Remove the screws on the monitor groove if needed before installing the stand.
Place the monitor on a soft, protected surface to avoid scratching the display panel.
Do not use any sharp objects on the panel.
The groove for installing the stand bracket can also be used for wall mount. Please contact
your dealer for proper wall mount kit.

ASROCK PG34WQ15R3A Specifications

General

Panel type	VA
Color gamut	91 %
Pixel pitch	0.23175 x 0.23175 mm
Display diagonal	34 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display technology	OLED
Native aspect ratio	21:9
Vertical scan range	48 - 165 Hz
Horizontal scan range	30 - 260 kHz
Screen curvature rating	1500R
Viewable size, vertical	333.72 mm
sRGB coverage (typical)	115 %
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	797.22 mm
Digital vertical frequency	48 - 100 Hz
Digital horizontal frequency	30 - 160 kHz
Display brightness (typical)	550 cd/m²
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	DisplayHDR 400
NVIDIA G-SYNC	-
AMD FreeSync type	FreeSync Premium
Charging port type	USB Type-C
DisplayPort version	1.4
Headphone connectivity	3.5 mm
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
RMS rated power	4 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Power consumption (off)	0.3 W
Power consumption (standby)	- W
Power consumption (typical)	65 W
Power consumption (PowerSave)	0.5 W
Package weight	13500 g
Cables included	Power, DisplayPort, HDMI, USB Type-A to USB Type-C
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	332.22 mm
Width (with stand)	809.34 mm
Height (with stand)	581.82 mm
Weight (with stand)	9630 g
Depth (without stand)	120.1 mm
Height (without stand)	365.84 mm
Weight (without stand)	6530 g
