13
A620I Lightning WiFi
WiFi Antennas Installation Guide
Step 1
Prepare the WiFi 2.4/5/6 GHz Antennas that
come with the package.
Step 2
Connect the two WiFi 2.4/5/6 GHz Antennas
to the antenna connectors. Turn the antenna
clockwise until it is securely connected.
Step 3
Set the WiFi 2.4/5/6 GHz Antenna as shown in
the illustration.
*You may need to adjust the direction of
the antenna for a stronger signal.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK PHANTOM GAMING A620I LIGHTNING WiFi and is the answer not in the manual?

ASROCK PHANTOM GAMING A620I LIGHTNING WiFi Specifications

General IconGeneral
Form FactorMini-ITX
ChipsetAMD A620
SocketAM5
Memory Slots2 x DIMM
Maximum Memory64GB
PCIe Slots1 x PCIe 4.0 x16
BluetoothBluetooth 5.2
Audio7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Memory SupportDDR5
Storage Interface4 x SATA3
USB Ports2 x USB 2.0
NetworkingWi-Fi 6E, 2.5G LAN
Video Outputs1 x HDMI, 1 x DisplayPort
