4
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x HDMI Port
•
2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)*
•
1 x USB 3.2 Gen1 Type-A Port*
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
•
2 x USB 2.0 Ports
•
1 x RJ-45 LAN Port
•
1 x BIOS Flashback Button
•
HD Audio Jacks: Line in / Front Speaker / Microphone
* USB32_23 are Lightning Gaming Ports.
Storage
CPU:
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
•
1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280
PCIe Gen3x4 (32 Gb/s) mode*
•
2 x SATA3 6.0 Gb/s Connectors
* Supports NVMe SSD as boot disks
RAID
•
Supports RAID 0 and RAID 1 for SATA storage devices
•
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe
storage devices*
* Requires additional M.2 NVMe expansion cards to support
RAID 10
Connector
•
2 x Addressable LED Headers*
•
2 x CPU/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)**
•
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)***
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
•
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
•
1 x Front Panel Type C USB 3.2 Gen1 Header
