ASROCK PHANTOM GAMING B650I LIGHTNING WiFi User Manual

6
1.3 Motherboard Layout
BIOS
ROM
ATXPWR1
DDR5_B1 (64 bit, 288-pin module)
DDR5_A1 (64 bit, 288-pin module)
AMD
B650
PCIE1
ATX 12V1
SATA3 _2
SATA3 _1
1
USB3 2_ 4_5
HDL ED RESE T
PLE D PWRBT N
PANEL1
1
1
USB32_TC2
USB_5_6
CLRCMOS1
1
M2_1
CHA _FAN1/ WP
1
SPE AKER1
1
HD_ AUDIO 1
CPU_FAN1/WP
CPU_FAN2/WP
ADDR_LED2
1
ADDR_LED1
1
AUDIO
CODEC
USB 3.2 Gen2
T: USB32_1
B: USB32_TC1
Top:
LAN
USB 3.2 Gen2
T: USB32_3
B: USB32_2
HDMI1
USB 2.0:
USB_1234
M2_WIFI_1
1
2
3
6
4
5
7
8
9
10
11
12
13
14
1517 16
Top:
LINE IN
Cent er :
FRONT
Bott om :
MIC IN
BIOS
_FB1
Top Side View

ASROCK PHANTOM GAMING B650I LIGHTNING WiFi Specifications

General

Chipset	AMD B650
Form Factor	Mini-ITX
Memory Slots	2
Maximum Memory	64GB
Memory Type	DDR5
Memory Support	DDR5 6400+(OC)
PCIe Slots	1 x PCIe 4.0 x16
LAN	2.5 Gigabit LAN
CPU Socket	AM5
Bluetooth	Bluetooth 5.2
Audio Codec	Realtek ALC1220
Storage Interface	4 x SATA3 6.0 Gb/s
WiFi	WiFi 6E (802.11ax)
RGB Support	Yes
M.2 Slots	2
USB Ports	4 x USB 3.2 Gen1 Type-A, 2 x USB 2.0
