Page #12 background imageLoading...
Page #12 background image
8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Addressable LED Header (ADDR_LED1)
3 Addressable LED Header (ADDR_LED2)
4 CPU/Water Pump Fan Connector (CPU_FAN1/WP)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
7 ATX Power Connector (ATXPWR1)
8 SATA3 Connector (SATA3_2)
9 SATA3 Connector (SATA3_1)
10 USB 3.2 Gen1 Header (USB32_4_5)
11 System Panel Header (PANEL1)
12 USB 2.0 Header (USB_5_6)
13 Front Panel Type C USB 3.2 Gen1 Header (USB32_TC2)
14 Clear CMOS Jumper (CLRCMOS1)
15 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
16 Front Panel Audio Header (HD_AUDIO1)
17 Chassis Speaker Header (SPEAKER1)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK PHANTOM GAMING B650I LIGHTNING WiFi and is the answer not in the manual?

ASROCK PHANTOM GAMING B650I LIGHTNING WiFi Specifications

General IconGeneral
ChipsetAMD B650
Form FactorMini-ITX
Memory Slots2
Maximum Memory64GB
Memory TypeDDR5
Memory SupportDDR5 6400+(OC)
PCIe Slots1 x PCIe 4.0 x16
LAN2.5 Gigabit LAN
CPU SocketAM5
BluetoothBluetooth 5.2
Audio CodecRealtek ALC1220
Storage Interface4 x SATA3 6.0 Gb/s
WiFiWiFi 6E (802.11ax)
RGB SupportYes
M.2 Slots2
USB Ports4 x USB 3.2 Gen1 Type-A, 2 x USB 2.0
