English
4
•
1 x Clear CMOS Button / Power Button
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
Storage
•
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
15 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug*
•
1 x Ultra M.2 Socket (M2_1), supports M Key type
2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2
PCI Express module up to Gen3 x4 (32 Gb/s)**
•
2 x Ultra M.2 Sockets (M2_2 and M2_3), support M Key
type 2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**
** Supports Intel® Optane
TM
Technology (M2_1)
** Supports NVMe SSD as boot disks
** Supports Virtual RAID On CPU (M2_2 and M2_3)
Connector
•
1 x Virtual RAID On CPU Header
•
1 x TPM Header
•
1 x Power LED and Speaker Header
•
1 x RGB LED Header
* Supports in total up to 12V/3A, 36W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* e CPU Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
•
1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Con-
trol)
* CPU_OPT/W_PUMP and CHA_FAN1 can auto detect if
3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector (Hi-Density Power Con-
nector)
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
To Next Page
