English
51
X299E-ITX/ac
CPU Conguration
CPU Ratio
e CPU speed is determined by the CPU Ratio multiplied with the BCLK. Increasing the
CPU Ratio will increase the internal CPU clock speed without aecting the clock speed of
other components.
CPU Mesh Max Ratio
Sets the maximum OC Ratio for the CPU Mesh Domain.
CPU Mesh Min Ratio
Sets the minimum OC Ratio for the CPU Mesh Domain.
Flex Ratio
Sets the value for the CPU Flex Ratio.
BCLK Frequency
e CPU speed is determined by the CPU Ratio multiplied with the BCLK.
Increasing the BCLK will increase the internal CPU clock speed but also aect the
clock speed of other components.
BCLK Step
e CPU speed is determined by the CPU Ratio multiplied with the BCLK.
Increasing the BCLK will increase the internal CPU clock speed but also aect the
clock speed of other components.
BCLK Reset Range
Conigure the BCLK Reset Range. Issue a reset when BCLK overclocking exceed this
range.
Stable Delay
Conigure the delay time aer BCLK settings for stable signals.
CPU PLL Spread Spectrum
Enable CPU PLL Spread Spectrum to reduce electromagnetic interference for
passing EMI tests. Disable to achieve higher clock speeds when overclocking.
SRC PLL Spread Spectrum
Enable SRC PLL Spread Spectrum to reduce electromagnetic interference for
passing EMI tests. Disable to achieve higher clock speeds when overclocking.
