2.3 Installation of Memory Modules (SO-DIMM)
is motherboard provides four 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots, and
supports Quad Channel Memory Technology.
Quad Channel Memory Conguration
DDR4_A1
Populated
DDR4_B1
Populated
DDR4_D1
Populated
DDR4_C1
Populated
•
If only two memory modules are installed in the DDR4 SO-DIMM slots, then Dual
Channel Memory Technology is activated. If three memory modules are installed, then
Triple Channel Memory Technology is activated.
1. For quad channel conguration, you always need to install identical (the same
brand, speed, size and chip-type) DDR4 SO-DIMM pairs.
2. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and SO-DIMM may be damaged.
3. e SO-DIMM only ts in one correct orientation. It will cause permanent damage
to the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at
incorrect orientation.
