ASROCK Z370M-ITX/ac User Manual

154
155
Bahasa Indonesia
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
1 x Giga PHY Intel® I219V, 1 x GigaLAN Intel® I211AT
•
Mendukung Wake-On-LAN
•
Mendukung Perlindungan dari Petir/ESD
•
Mendukung Ethernet Hemat Energi 802.3az
•
Mendukung PXE
LAN Nirkabel
•
Intel® 802.11ac WiFi Modul
•
Mendukung IEEE 802.11a/b/g/n/ac
•
Mendukung Dual-Band (2,4/5 GHz)
•
Mendukung Sambungan nirkabel berkecepatan tinggi hingga
433Mbps
•
Mendukung Bluetooth 4.2 / 3.0 + Kecepatan tinggi kelas II
I/O Panel
Belakang
•
2 x Port Antena
•
1 x Port Mouse/Keyboard PS/2
•
2 x Port HDMI
•
1 x DisplayPort 1.2
•
2 x Port USB 2.0 (Mendukung Perlindungan dari ESD)
•
6 x Port USB 3.1 Gen1 (Mendukung Perlindungan dari ESD)
•
2 x Port LAN RJ-45 dengan LED (LED ACT/LINK dan LED
SPEED)
•
Soket Audio HD: Saluran Masuk/Speaker Depan/Mikrofon
Penyimpanan
•
6x Konektor SATA3 6,0 Gb/s, mendukung RAID (RAID 0, RAID
1, RAID 5, RAID 10, Intel Rapid Storage Technology 15), NCQ,
AHCI, dan Hot Plug*
* Jika M2_1 digunakan perangkat SATA tipe M.2, maka SATA3_0
akan dinonaktian.
•
1 Soket Ultra M.2, mendukung modul M Key tipe
2230/2242/2260/2280 M.2 SATA3 6,0 Gb/s dan modul M.2 PCI
Express hingga Gen3 x4 (32 Gb/s)**
** Mendukung Teknologi Intel® Optane
TM
** Mendukung SSD NVMe sebagai disk boot
** Mendukung Kit ASRock U.2

ASROCK Z370M-ITX/ac Specifications

General

ECC	No
Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 4000 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Z370
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
Number of SATA connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI
ACPI version	6.0
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel I211-AT, Intel I219V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	- mm
Width	170 mm
