ASROCK Z370M-ITX/ac User Manual

154
155
Z370M-ITX/ac
Bahasa Indonesia
Konektor
•
1 x Header TPM
•
1 x Header Chassis Intrusion
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis (4-pin)
•
1 x Konektor Sasis Opsional/Kipas Pompa Air (4-pin)
* Sasis Opsional/Kipas Pompa Air mendukung kipas berpendingin
air dengan daya kipas maksimum 1,5A (18W).
•
1 x Konektor Daya ATX 24 pin
•
1 x Konektor Daya 8 pin 12V
•
1 x Konektor Audio Panel Depan
•
1 x Header USB 2.0 (Mendukung 2 port USB 2.0)
(Mendukung Perlindungan dari ESD)
•
1 x Header USB 3.1 Gen1 (Mendukung 2 port USB 3.1 Gen1)
(Mendukung Perlindungan dari ESD)
Fitur BIOS
•
AMI UEFI Legal BIOS dengan dukungan GUI multibahasa
•
ACPI 6.0 Kompatibel dengan aktivitas pengaktifan
•
Dukungan SMBIOS 2.7
•
CPU, DRAM, PCH 1,0V, VCCST, Multipengatur Tegangan CPU
Internal PLL
Monitor
Perangkat
Keras
•
Deteksi Suhu: Kipas CPU, Sasis, Sasis Opsional, Pompa Air
•
Takometer Kipas: Kipas CPU, Sasis, Sasis Opsional, Pompa Air
•
Kipas Hening (Penyesuaian otomatis kecepatan kipas sasis
berdasarkan suhu CPU): Kipas CPU, Sasis, Sasis Opsional, Pompa
Air
•
Kontrol Multikecepatan Kipas: Kipas CPU, Sasis, Sasis Opsional,
Pompa Air
•
Deteksi CASE OPEN
•
Pemantauan voltase: +12V, +5V, +3,3V, CPU Vcore
OS
Microso® Windows® 10 64-bit
Sertikasi
•
FCC, CE
•
Mendukung ErP/EuP (memerlukan catu daya untuk ErP/EuP)

ASROCK Z370M-ITX/ac Specifications

General

ECC	No
Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 4000 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® Z370
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
Number of SATA connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI
ACPI version	6.0
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel I211-AT, Intel I219V
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	- mm
Width	170 mm
