Z690M PG Riptide/D5
+0.82V PCH Voltage
Congure the chipset voltage (0.82V).
+1.05V PCH Voltage
Congure the chipset voltage (1.05V).
VCCIN AUX Voltage
Congure the voltage for the VCCIN AUX.
+1.8V PROC Voltage
Congure the CPU voltage (1.8V).
+1.05V PROC Voltage
Congure the CPU voltage (1.05V).
DDR5 PMIC Conguration
VDD Voltage
Congure the memory VDD Voltage.
VDD Voltage Range
Congure the memory VDD Voltage Range.
VDDQ Voltage
Congure the memory VDDQ Voltage.
VDDQ Voltage Range
Congure the memory VDDQ Voltage Range.
VPP Voltage
Congure the memory VPP Voltage.
VDD Eventual Voltage
Congure the memory VDD Eventual Voltage.
VDDQ Eventual Voltage
Congure the memory VDDQ Eventual Voltage.
VPP Eventual Voltage
Congure the memory VPP Eventual Voltage.
PLL Voltage Conguration
