7
Audio
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
Premium Blu-ray audio support
LAN
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
RTL8111E-VL
Supports Wake On LAN
Supports LAN Cable Detection
Supports Energy Efcient Ethernet 802.3az
Supports PXE
Rear Panel
I/O
1 x DC Jack
1 x DVI-I Port
1 x HDMI Port
1 x eSATA Connector
2 x USB 3.0 Ports (H61TM-ITX by Etron EJ188)
2 x USB 2.0 Ports
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
HD Audio Jacks: Front Speaker / Microphone
Connectors
2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel
Smart Response Technology), NCQ, AHCI and “Hot Plug”
functions (Z77TM-ITX / H77TM-ITX)
1 x SATA3 6.0 Gb/s connector and 1 x SATA2 3.0 Gb/s con-
nector, support NCQ, AHCI and Hot Plug functions (B75TM-
ITX)
2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug (H61TM-ITX)
1 x CIR header
1 x COM port header
1 x HDMI_SPDIF header
1 x LVDS connector
1 x LPC Debug header
1 x Home Theater PC header
1 x CPU Fan connector (4-pin)
1 x Chassis Fan connector (4-pin)
1 x Front Panel Audio connector
1 x Analog Surround Audio header
1 x Digital MIC header
1 x 3W Audio AMP Output Wafer header
1 x SATA Power connector
