6 Appendix
Selecting the correct EAC address (AH15/AH30)
Selecting EAC addresses for communication hubs
and locks correctly during installation is important
in order not to cause address conflicts in your
installation.
The communication hubs can use different
address ranges depending on the installation:
∙ Address 1-15: For AH30 communication hubs
with one or several locks paired and AH15
communication hubs. Address is selected by DIP
Switch or the Programming Application.
∙ Address 16-31: For AH30/AH15 communication
hubs in single device mode (only one lock
paired). Address is selected by DIP Switch or the
Programming Application.
∙ Address 32-63: For AH30/AH15 communication
hubs in single device mode (only one lock
paired). Address is selected only by the
Programming Application.
The final lock EAC address depends on the
communication hub address. For AH15
communication hubs the lock address is equal to
the hub address. For AH30 communication hubs
the lock address is decided by the addressing
table.
Addressing table – normal address offset
An AH30 communication hub can pair with
up to 8 locks. When pairing several locks to a
communication hub, the following addresses are
used for the address range 1-15. Above this range
only one lock can be paired.
DIP 4 – DIP 1 AH30 Hub address Lock addresses
0000 Reserved
0001 0x01 0x01, 0x11, 0x21, 0x31, 0x41, 0x51, 0x61, 0x71
0010 0x02 0x02, 0x12, 0x22, 0x32, 0x42, 0x52, 0x62, 0x72
0011 0x03 0x03, 0x13, 0x23, 0x33, 0x43, 0x53, 0x63, 0x73
0100 0x04 0x04, 0x14, 0x24, 0x34, 0x44, 0x54, 0x64, 0x74
0101 0x05 0x05, 0x15, 0x25, 0x35, 0x45, 0x55, 0x65, 0x75
0110 0x06 0x06, 0x16, 0x26, 0x36, 0x46, 0x56, 0x66, 0x76
0111 0x07 0x07, 0x17, 0x27, 0x37, 0x47, 0x57, 0x67, 0x77
1000 0x08 0x08, 0x18, 0x28, 0x38, 0x48, 0x58, 0x68, 0x78
1001 0x09 0x09, 0x19, 0x29, 0x39, 0x49, 0x59, 0x69, 0x79
1010 0x0A 0x0A, 0x1A, 0x2A, 0x3A, 0x4A, 0x5A, 0x6A, 0x7A
1011 0x0B 0x0B, 0x1B, 0x2B, 0x3B, 0x4B, 0x5B, 0x6B, 0x7B
1100 0x0C 0x0C, 0x1C, 0x2C, 0x3C, 0x4C, 0x5C, 0x6C, 0x7C
1101 0x0D 0x0D, 0x1D, 0x2D, 0x3D, 0x4D, 0x5D, 0x6D, 0x7D
1110 0x0E 0x0E, 0x1E, 0x2E, 0x3E, 0x4E, 0x5E, 0x6E, 0x7E
1111 0x0F 0x0F, 0x1F, 0x2F, 0x3F, 0x4F, 0x5F, 0x6F, 0x7F
When configuring installations that differ from
the default configuration described in section DIP
1-5 – Selecting the EAC address/Automatic paring
on page 38, use this table to keep track of what
addresses are used by the locks/sensors in your
installation in order to avoid addressing conflicts
according to section "Installation examples" on page
44 for mixed installations.
