BASIC SETUP – START HERE
The symbols below is used to describe the programming of the lock. ALL PROGRAMMING SHOULD BE MADE
WITH THE DOOR OPEN AND CODES SHOULD BE TESTED BEFORE CLOSING THE DOOR THE FIRST TIME.
Push the Hash button Push the Star button Green light indication Red Light indication
When the lock is in Factory Mode and the battery is entered a quick set up can be used to set up the lock into
3 different modes. To use the standard programming menus instead, simply push . The following options on
how to deploy the lock is available.
NOTE: In quick set up it’s very important to enter the correct numbers of digits in order to set the lock into the
correct mode.
A: QUICK SETUP OF MASTER CODE AND USER CODE FOR USE IN PRIVATE MODE
[Chosen Master Code] [Chosen User Code] (flashes red if incorrect number of digits is entered)
Ex: * 12345678 1111 * will add new Master Code 12345678 and User Code 1111 and set the lock into Private Mode
and lock.
B: REGISTRERING AVB: QUICK SETUP OF MASTER CODE FOR USE IN PUBLIC MODE
[Chosen Master Code] (flashes red if incorrect number of digits is entered)
Ex: * 12345678 * will add new Master Code 12345678 and set the lock into Public Mode and stay open.
C: QUICK SETUP OF MASTER CODE AND JANITOR CODE FOR USE IN PUBLIC MO
[Chosen Master Code] [Chosen Janitor Code] (flashes red if incorrect number of digits is entered)
Ex: * 12345678 112233 * will add new Master Code 12345678 and Janitor Code 112233 and set the lock into
Public Mode.
MOVE FROM FACTORY MODE TO PUBLIC MODE WITH PREDEFINED MASTER CODE 11111111
[Press and hold for 2 seconds] (Release after flashes)
Ex: # will set the lock to standard mode with predefined Master Code 1111 1111 and set the lock into Public Mode.
For further programming, se menu points below
NOTE: If this option is chosen, it’s very important to change the predefined master code to keep security.
STANDARD PROGRAMMING MENUES (REQUIRES BASIC SETUP)
1: MODIFY USER CODES WITH MASTER CODE (ONLY PRIVATE MODE)
10: Add new User Code
(MASTER CODE) 10 (NEW USER CODE)
Ex: # 12345678 # 10 # 9999 # will add new User Code 9999
11: Delete User Code
(MASTER CODE) 11 (USER CODE TO DELETE)
Ex: # 12345678 # 11 # 9999 # will delete User Code 9999 (if it was previously added)
12: Add multiple User Codes
(MASTER CODE) 12 (FIRST CODE TO ADD) (NEXT CODE TO ADD) (LAST CODE TO ADD)
Ex: # 12345678 # 12 # 9999 * 8888 * 7777 * 6666 # will add four new user codes 9999,8888,7777,6666
13: Delete multiple User Codes
(MASTER CODE) 13 (FIRST CODE TO DELETE) ((NEXT CODE TO DELETE)
(LAST CODE TO DELETE)
Ex: # 12345678 # 13 # 9999 * 8888 # will delete User Codes 9999 and 8888
Electro-mechanical Lock Model ML53PA
ASSA ABLOY PIN
